What is the meaning of hard connection of LED display screen

In fact, the so-called hard connected LED display screen is a concept introduced only in recent years. In short, hard connection is to integrate all the connecting wires into the box or module. During installation, there is no need to connect the wires. You only need to connect all the modules or boxes according to Zhao, which reduces the bondage of the wires, makes the installation faster and increases the aesthetics.

Traditional connection mode at present, Le displays are spliced by boxes or modules. A box is about the size of four modules. During splicing, they should be connected with the power line through the signal line to share the current signal, so that the image can be enlarged and displayed. In the traditional case, the connection mode is the cable slot behind the LED display module or box, which needs technicians to connect one by one. Therefore, we can see that after the installation of this traditional structure, many wires will be scattered behind the LED display screen, which looks messy. At the same time, it is also laborious during installation, which needs to be unplugged and plugged one by one, resulting in the failure of installation

2、 What is hard connection? It changes the traditional way of soft connection with multiple wires. A more beautiful and simple hard connection Le is the push-out of the display screen structure. It concentrates all the wires in the box or module. No wires can be seen on the surface, but there are two interfaces at the top and bottom. Technicians only need to connect the interfaces directly during installation, In this way, the installation can be realized both in front of and behind the LED screen. Most of the hard connected display screens are box structure. Of course, some modules use hard connection. It greatly integrates the aggregation of Le structure and makes the whole installation easier. 3、 The advantage of hard connection the hard connection of LED display screen has no wire. On the one hand, the installation speed is improved. On the other hand, it also reduces the occurrence of some after-sales problems caused by wire faults, thus reducing the after-sales rate. In addition, there is no connection of various wires, which also makes the whole ed display more beautiful and tidy. At the same time, the hard connection of LED display can also realize the front maintenance installation, so there is no need to reserve the maintenance space after installation, which greatly saves the space requirements and makes the maintenance more convenient. In fact, the hard connection of LED display screen is to integrate the line into the box or module, which reduces the binding of the line, makes the installation simpler, the screen more beautiful and the after-sales more convenient. With the continuous embodiment of its advantages, the LED screen with hard connection structure has gradually become a mainstream connection mode
